Formerly Adapta Flex™ Hose
(Specification 3204E, 3204S, 3204E, 3204S, 3204E, 3204EB, 3204SB, 3204EB, 3204SB, 3204BL, GR, YL)
RECOMMENDED FOR: Air and water applications requiring maximum flexibility in any industry, including mining, construction, agriculture, vehicle repair and in-plant operations. Outstanding resistance to heat and ozone. Suitable for light agricultural spraying, such as dilute solutions of herbicides.
TEMPERATURE: -40°C to +93°C continuous service.
CONSTRUCTION: Tube: Type P (EPDM). Black.
Reinforcement: Synthetic, high tensile textile cord.
Cover: Type P (EPDM). Blue, Green or Yellow. All sizes through 1/2" are perforated.
Design Factor: 3:1
COUPLINGS: 19 (up through 1/2" only), 1, 3 or 4, (up through 1/2" with 20 brass ferrules, up through 1" with bands), 72 Gates Power Crimp® or 75 Gates GLX®. Reference the Hose Coupling Section.
PACKAGING: Minimum of 90% of hose reels will be 1-piece lengths.
3/8" through 3/4": Packaged in 152m to 213m reels. Maximum 2 pieces in 15m increments.
3/4" x 15m: Packaged 61m per carton, each length coiled and tied.
BRANDING: Continuous ink brand. Example: “Gates® Plant Master® 250 3/8 INCH (9.5mm) 300 PSI (2.07MPa) WP Made in USA”
SPECIAL ORDER REQUIREMENTS: Special production runs require minimum order quantities of 7620 meters per size.
REMNANT LENGTHS: None.
STANDARDS: Tube: ARPM (Class C) Limited oil resistance.
